How to Set/Reset Lux/Luxpro Thermostat

Lux and Luxpro are historically based companies that originated from the Lux Clock company that was founded in 1914 in Connecticut. Lux Products produces world class thermometers and thermostats. Since Lux thermostats have a 99.6% reliability rating, it is indeed unsettling when your Lux/Luxpro thermostat fails or is simply not working properly. Read in to learn how you can troubleshoot problems with your Lux/Luxpro Thermostat and how you can reset it.

If you want to know how to reset your Lux/Luxpro Thermostat, locate the reset button on your Luxpro Thermostat. It will appear as a small white button that has HW Reset, or R. Reset stamped on it. Press and then hold this Reset Button for approximately five seconds. You will see the screen start to blink and the thermostat will then reset itself.

Adjusting the thermostat cooling

How to Reset Lux/Luxpro Thermostat Change Filter

thermostat on the wall

Usually, after a proscribed number of days of running your Lux/Luxpro Thermostat, you will get a flashing automatic message on the display of the thermostat that is a reminder to you to change the air filter of your HVAC System.  This message will usually read Change Filter.

If you want to set/reset your Lux/Luxpro Thermostat and reset your Lux/Luxpro Change Filter monitoring, turn the Dial to the Air Filter Setting and then use the arrows to choose the number of days that you want to pass until you will need to change the air filter again.

How to Override Lux/Luxpro Thermostat

Adjusting the thermostat cooling

If your Lux/Luxpro Thermostat is not functioning properly, it may be time for an override of the Thermostat system. Following the troubleshooting steps as outlined below can help you to reset your Lux/Luxpro Thermostat once again.

If you want to set/reset your Lux/Luxpro Thermostat and override your Lux/Luxpro Thermostat, place dip switch #2 that you can locate on the back of the thermostat and then press on the HW_RST which will delete all the installed programming features from your thermostat.

The display should now read Override when you raise or lower the set temperature in any change from the programmed temperature.

How to Unlock the Lux/Luxpro Thermostat

thermostat on the wall

If you find that somehow your Lux/Luxpro Thermostat has inadvertently locked, it can often take some time to figure out what happened. Sometimes, the children of visiting relatives or friends may have played with the thermostat’s buttons and just locked the thermostat.

If you want to set/reset your Lux/Luxpro Thermostat and you also want to learn how to unlock your Lux/Luxpro Thermostat, press the Next Button and hold it for five seconds. Now you will see the message Enter Code. Go ahead and enter the same code you used to lock your thermostat.

Use Next and the UP/Down Buttons to change the numbers currently listed and then press Next and your Lux/Luxpro Thermostat will be unlocked.

Since every model of Lux/Luxpro thermostats has individualized locking mechanisms, it may take careful troubleshooting to determine the cause of this issue so that you can rapidly resolve it.

How to Adjust a Luxpro Thermostat

thermostat on the wall

If the temperature in your home needs adjusting, you can easily and quickly adjust your Lux/Luxpro Thermostat by following the steps as outlined below.

If you want to learn how to reset your Lux/Luxpro Thermostat and want to learn how to adjust your Lux/Luxpro Thermostat, you will need to use the thermostat buttons. If you want to increase the temperature setting on your Lux/Luxpro Thermostat, use the right or top button.

To decrease the temperature, use the left or bottom buttons.

How to Set Temp on Luxpro Thermostat

Adjusting the thermostat cooling

If you want to change the default temperatures on your Luxpro Thermostat, you can use the System Mode Switch to either choose Heat or Cool.

If you want to learn how to reset your Lux/Luxpro Thermostat and want to know how to set the temperature on your Lux/Luxpro Thermostat, press either the Up or Down Arrows to get to your desired temperature.

If you happen to have a Heat Only Luxpro Thermostat, you will only have settings for heat for the colder months of autumn and winter.

On the thermostat’s digital display, select the Heating Mode. Press on either the Down or Up Buttons until you finally see the words Set appear as a message. Now, you should see the temperature number flashing and at this point you can adjust the current temperature value.

If you have a P711 Lux/Luxpro Model, there is a temperature setting which is pre-programmed. The pre-programmed temperatures are based on a schedule which is based on an hourly schedule.

In the daytime, at 6 am, the heating mode will raise the temperature to a level of seventy degrees Fahrenheit.  Beginning at the time of six am.

The Cool Mode will decrease the temperature to 78 degrees Fahrenheit. Nighttime is considered to start at ten pm when the heating level is automatically raised to 62 degrees Fahrenheit. The Cool Mode will adjust the temperature to a level of 75 degrees Fahrenheit.

To choose these default levels, you can easily use the heat and cool switches by pressing the Up and Down Buttons to set the temperatures for both heating and cooling at the appropriate levels.

How to Set Time on Luxpro Thermostat

Adjusting the thermostat cooling

It is important to be able to set the time on your Luxpro Thermostat to be able to maintain your orientation and normal routines. Follow the steps below to set the time on your Luxpro Thermostat.

To learn how to set/reset your Lux/Luxpro Thermostat and learn how to reset the time on your Lux/Luxpro Thermostat, Set the System Mode to the Off position. Now, press the Set Button one time. And you will see the Screen Flashing. Press Next to Advance to Setting of the Clock.

You will see the Time Setting Flashing and can use the Up or Down Arrows to set the clock.

How to Open Luxpro Thermostat

thermostat on the wall

If you need to open your Luxpro Thermostat, this can be accomplished in several easy steps. Follow the steps as outlined below to address this issue.

If you need to learn how to reset your Lux/Luxpro Thermostat, and you need to learn how to open your Luxpro Thermostat, Press and then Release the Next Button that is in the middle of the Thermostat’s programming panel a total of 3 times. Then Press and then Release the Hold Button

This will then relock the Thermostat.

How to Lock Luxpro Thermostat

Adjusting the thermostat cooling

If you need to lock your Luxpro Thermostat to avoid the possibility of it being tampered with, you can take the steps outlined below to quickly lock your Thermostat.

If you need to learn how to reset your Lux/Luxpro Thermostat and you need to learn how to relock your Luxpro Thermometer, set the System Mode Switch to either Cool or Heat and then keep the Slide Switch in the Run Position. Then, Press and Hold the Next Button for a period of five seconds.

Copyright protected content owner: ReadyToDIY.com and was initially posted on February 10, 2022.

Now, you will see a Lock Screen Code. Go ahead and enter this code to use for locking the Thermostat. Use the UP/Down and the Next Button to either Advance or Reverse just as you did when you were unlocking the Thermostat.

Press the Next Button for a period of about five seconds. At this point, if you do see the Padlock icon, it means that the Thermostat has indeed been locked.

If this does not result in locking your thermostat, you can try to conduct a soft reset. Look for the small white button that is located right above the Next Button and is within the Thermostat wall.

This small white button is the Software Reset Button. You can easily use either a bent paperclip or a pencil to press it.

How to Turn Off Luxpro Thermostat

Adjusting the thermostat cooling

Even though Luxpro Thermostats are extremely reliable and useful, occasionally you may need to turn off your Luxpro Thermostat. This includes times when you may suddenly find that the room you are in has suddenly turned freezing cold or has become exceedingly hot. Read on to see what you can do to turn off your Luxpro Thermostat.

If you want to set/reset your Lux/Luxpro Thermostat and want to know how to turn off your Luxpro Thermostat, first try to replace the batteries in the Thermostat. Then, check the circuit breakers and make sure that none of the wires are not working properly and are in perfect working order.

Check to see if your Luxpro Thermostat is showing low battery levels. If this is not the problem, check to make sure that the Thermostat is indeed receiving enough power.

If not enough power is being supplied to the Thermostat, check to see if any of the circuit breakers have tripped because of some electrical issue or because of a short circuit of some kind.

You can also check the contacts on the Subbase. They will appear as 2 brass prongs that are located on the wire terminals above the letters that are on the wire terminals.

If you are indeed having any problems with the heating and cooling functions of your thermostat, you can try to press the two contacts together in a gentle fashion so as not to cause any damage to them.

In addition, you can attempt to clean the single contact pens that are on the Circuit Board. You can try to use a pencil eraser to accomplish this.

Another possible fix to this problem is to analyze the Dip Switches which you can find on the posterior part of the Thermostat.

Be sure that Switch number one is in the On Position and that the Fan Switch is in the Electric Position.

Now, restart your Lux/Luxpro Thermostat.

Check all the connectors to make sure that they are all connected to their appropriate terminals as directed by your owner’s manual. Also, check all the wiring to be sure it is not the reason for problems with your thermostat.

Use a Multimeter to be sure that the line voltage is intact and that a voltage problem is not what is causing the problems with your Luxpro Thermostat.

Look for any sign that the keyboard is locked. If so, you should be able to see a Locked Keyboard Message.

Go ahead and tap on Unlock the Keyboard.  Then select OK and then the Up and Down arrows so you can enter your Lock Code.

When your Luxpro turns back on, it will be unlocked.

If the display appears hard to read or illegible, it may be necessary to take the plastic off of the display so that is more readable.

Copyright article owner is ReadyToDiy.com for this article. This post was first published on February 10, 2022.

If the display is not easily readable, it is probably due to batteries that are running low. If you see a message reading Override, it is usually because of an irregular increase in temperature that is drastically different to the values programmed into your Luxpro Thermostat.

This reading should just simply disappear when the next temperature you have scheduled is reached.

If you see an Error Code indicating HI or Low, it usually means that your room’s temperature has gone beyond the acceptable range for your thermostat.

You will be able to see this reading on the display screen at the time the temperature in a particular room has returned to the normal range.

Another way to attempt to turn off the Luxpro Thermostat is to restart the Thermostat. If you look under the display screen you will see a few buttons on a cover. Look for the Power Button and then press it. This will turn the Thermostat off and you can press the Power Button again to turn the unit back on again.
